Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	1N4148 Datasheet
Standard Package	10000
Manufacturer	Micro Commercial Co
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	75V
Current - Average Rectified (Io)	150mA
Voltage - Forward (Vf) (Max) @ If	1V @ 10mA
Speed	Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr)	4ns
Current - Reverse Leakage @ Vr	5µA @ 75V
Capacitance @ Vr, F	4pF @ 0V, 1MHz
Mounting Type	Through Hole
Package / Case	DO-204AH, DO-35, Axial
Supplier Device Package	DO-35
Operating Temperature - Junction	-65°C ~ 175°C
Base Part Number	1N4148

SMMSD4148T1G	ON Semiconductor, Diode Standard 100V 200mA (DC) Surface Mount SOD-123,	View
BAS321,115	Nexperia USA Inc., Diode Standard 200V 250mA (DC) Surface Mount SOD-323,	View
BAS21-E3-18	Vishay Semiconductor Diodes Division, Diode Standard 200V 200mA Surface Mount SOT-23,	View
MUR460S R7G	Taiwan Semiconductor Corporation, Diode Standard 600V 4A Surface Mount DO-214AB (SMC),	View
US1M-E3/61T	Vishay Semiconductor Diodes Division, Diode Standard 1000V 1A Surface Mount DO-214AC (SMA),	View
D8020LTP	Littelfuse Inc., Diode Standard 800V 12.7A Through Hole TO-220AB-L,	View
CMMR1U-04 TR	Central Semiconductor Corp, Diode Standard 400V 1A Surface Mount SOD-123F,	View
MMSD103T1G	ON Semiconductor, Diode Standard 250V 200mA (DC) Surface Mount SOD-123,	View
GI506-E3/54	Vishay Semiconductor Diodes Division, Diode Standard 600V 3A Through Hole DO-201AD,	View
STTH1R02Q	STMicroelectronics, Diode Standard 200V 1.5A Through Hole DO-15,	View
VS-6EVL06-M3/I	Vishay Semiconductor Diodes Division, Diode Standard 600V 6A Surface Mount SlimDPAK, eSMP®	View
DA3X101K0L	Panasonic Electronic Components, Diode Standard 80V 100mA (DC) Surface Mount Mini3-G3-B,	View

1N4148-TP
