2N6039G

2N6039G

Part Number2N6039G

ManufacturerON Semiconductor

DescriptionTRANS NPN DARL 80V 4A TO225AA

Datasheet2N6034(35, 36, 38,39)

Package / CaseTO-225AA, TO-126-3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN - Darlington 80V 4A 40W Through Hole TO-225AA

To learn about the specification of 2N6039G, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add 2N6039G with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of 2N6039G.
We are offering 2N6039G for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

2N6039G - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Datasheet	2N6034(35, 36, 38,39)
Standard Package	500
Manufacturer	ON Semiconductor
Series	-
Packaging	Bulk
Part Status	Active
Transistor Type	NPN - Darlington
Current - Collector (Ic) (Max)	4A
Voltage - Collector Emitter Breakdown (Max)	80V
Vce Saturation (Max) @ Ib, Ic	3V @ 40mA, 4A
Current - Collector Cutoff (Max)	100µA
DC Current Gain (hFE) (Min) @ Ic, Vce	750 @ 2A, 3V
Power - Max	40W
Frequency - Transition	-
Operating Temperature	-65°C ~ 150°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-225AA, TO-126-3
Supplier Device Package	TO-225AA
Base Part Number	2N6039
