2SC3974

Part Number2SC3974

ManufacturerPanasonic Electronic Components

DescriptionTRANS NPN 500V 7A TOP-3F

Datasheet2SC3974 Datasheet

Package / CaseTOP-3F

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN 500V 7A 20MHz 3W Through Hole TOP-3F-A1

To learn about the specification of 2SC3974, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add 2SC3974 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of 2SC3974.
We are offering 2SC3974 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

2SC3974 - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single

Datasheet

2SC3974 Datasheet

Standard Package

Manufacturer

Panasonic Electronic Components

Series

Packaging

Bulk

Part Status

Obsolete

Transistor Type

NPN

Current - Collector (Ic) (Max)

Voltage - Collector Emitter Breakdown (Max)

500V

Vce Saturation (Max) @ Ib, Ic

1V @ 800mA, 4A

Current - Collector Cutoff (Max)

100µA (ICBO)

DC Current Gain (hFE) (Min) @ Ic, Vce

8 @ 4A, 5V

Power - Max

Frequency - Transition

20MHz

Operating Temperature

150°C (TJ)

Mounting Type

Through Hole

Package / Case

TOP-3F

Supplier Device Package

TOP-3F-A1
