Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	ZLQ Series
Standard Package	1000
Manufacturer	Rubycon
Series	ZLQ
Packaging	Bulk
Part Status	Active
Capacitance	2200µF
Tolerance	±20%
Voltage - Rated	6.3V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	4000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	1.162A @ 120Hz
Ripple Current @ High Frequency	1.66A @ 100kHz
Impedance	27 mOhms
Lead Spacing	0.138" (3.50mm)
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.866" (22.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

25ZLQ330MEFC8X11.5	Rubycon, 330µF 25V Aluminum Electrolytic Capacitors Radial, Can 4000 Hrs @ 105°C, ZLQ	View
6.3ZLQ2200MEFC8X20	Rubycon, 2200µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 4000 Hrs @ 105°C, ZLQ	View
10ZLQ3900MEFC12.5X20	Rubycon, 3900µF 10V Aluminum Electrolytic Capacitors Radial, Can 6000 Hrs @ 105°C, ZLQ	View
10ZLQ1800MEFC8X20	Rubycon, 1800µF 10V Aluminum Electrolytic Capacitors Radial, Can 4000 Hrs @ 105°C, ZLQ	View
25ZLQ3300MEFC12.5X35	Rubycon, 3300µF 25V Aluminum Electrolytic Capacitors Radial, Can 6000 Hrs @ 105°C, ZLQ	View
35ZLQ56MEFC5X11	Rubycon, 56µF 35V Aluminum Electrolytic Capacitors Radial, Can 3000 Hrs @ 105°C, ZLQ	View
35ZLQ220MEFC8X11.5	Rubycon, 220µF 35V Aluminum Electrolytic Capacitors Radial, Can 4000 Hrs @ 105°C, ZLQ	View
6.3ZLQ12000MEFC16X25	Rubycon, 12000µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 6000 Hrs @ 105°C, ZLQ	View
35ZLQ1500MEFC12.5X30	Rubycon, 1500µF 35V Aluminum Electrolytic Capacitors Radial, Can 6000 Hrs @ 105°C, ZLQ	View
10ZLQ3300MEFC10X25	Rubycon, 3300µF 10V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, ZLQ	View
25ZLQ680MEFC8X20	Rubycon, 680µF 25V Aluminum Electrolytic Capacitors Radial, Can 4000 Hrs @ 105°C, ZLQ	View
6.3ZLQ1800MEFC10X12.5	Rubycon, 1800µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, ZLQ	View

6.3ZLQ2200MEFC8X20
