Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	60S05-10
Standard Package	1
Manufacturer	Micro Commercial Co
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	100V
Current - Average Rectified (Io)	6A
Voltage - Forward (Vf) (Max) @ If	1V @ 6A
Speed	Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	5µA @ 100V
Capacitance @ Vr, F	150pF @ 4V, 1MHz
Mounting Type	Through Hole
Package / Case	DO-201AD, Axial
Supplier Device Package	DO-201AD
Operating Temperature - Junction	-55°C ~ 150°C
Base Part Number	60S1
