Categories	Capacitors / Ceramic Capacitors
Datasheet	885012206002 Drawing
Standard Package	1
Manufacturer	Wurth Electronics Inc.
Series	WCAP-CSGP
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	1µF
Tolerance	±10%
Voltage - Rated	6.3V
Temperature Coefficient	X7R
Operating Temperature	-55°C ~ 125°C
Features	-
Ratings	-
Applications	General Purpose
Mounting Type	Surface Mount, MLCC
Package / Case	0603 (1608 Metric)
Size / Dimension	0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max)	-
Thickness (Max)	0.037" (0.95mm)
Lead Spacing	-
Lead Style	-
