Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	A765 Series
Standard Package	1000
Manufacturer	KEMET
Series	A765
Packaging	Tape & Reel (TR)
Part Status	Active
Type	Polymer
Capacitance	150µF
Tolerance	±20%
Voltage - Rated	10V
ESR (Equivalent Series Resistance)	22mOhm
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	116mA @ 120Hz
Ripple Current @ High Frequency	2.32A @ 100kHz
Lead Spacing	-
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD
