AO3162


AO3162

Part NumberAO3162

Manufacturer

Description

Datasheet

Package / CaseTO-236-3, SC-59, SOT-23-3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

AO3162 - Product Attributes

Categories Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet
Standard Package1
ManufacturerAlpha & Omega Semiconductor Inc.
Series-
PackagingCut Tape (CT)
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)600V
Current - Continuous Drain (Id) @ 25°C34mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)10V
Rds On (Max) @ Id, Vgs500Ohm @ 16mA, 10V
Vgs(th) (Max) @ Id4.1V @ 8µA
Gate Charge (Qg) (Max) @ Vgs0.15nC @ 10V
Vgs (Max)±30V
Input Capacitance (Ciss) (Max) @ Vds6pF @ 25V
FET Feature-
Power Dissipation (Max)1.39W (Ta)
Operating Temperature-50°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackageSOT-23
Package / CaseTO-236-3, SC-59, SOT-23-3
