AON6973A

Part NumberAON6973A

ManufacturerAlpha & Omega Semiconductor Inc.

DescriptionMOSFET 2N-CH 30V 22A/30A 8DFN

DatasheetAON6973A

Package / Case8-PowerVDFN

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array 2 N-Channel (Half Bridge) 30V 22A, 30A 3.6W, 4.3W Surface Mount 8-DFN (5x6)

To learn about the specification of AON6973A, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add AON6973A with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of AON6973A.
We are offering AON6973A for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

AON6973A - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays

Datasheet

AON6973A

Standard Package

3000

Manufacturer

Alpha & Omega Semiconductor Inc.

Series

SRFET™

Packaging

Tape & Reel (TR)

Part Status

Obsolete

FET Type

2 N-Channel (Half Bridge)

FET Feature

Logic Level Gate

Drain to Source Voltage (Vdss)

30V

Current - Continuous Drain (Id) @ 25°C

22A, 30A

Rds On (Max) @ Id, Vgs

5.2mOhm @ 20A, 10V

Vgs(th) (Max) @ Id

2.2V @ 250µA

Gate Charge (Qg) (Max) @ Vgs

22nC @ 10V

Input Capacitance (Ciss) (Max) @ Vds

1037pF @ 15V

Power - Max

3.6W, 4.3W

Operating Temperature

-55°C ~ 150°C (TJ)

Mounting Type

Surface Mount

Package / Case

8-PowerVDFN

Supplier Device Package

8-DFN (5x6)
