APT100GN60LDQ4G

APT100GN60LDQ4G

Part NumberAPT100GN60LDQ4G

ManufacturerMicrosemi Corporation

DescriptionIGBT 600V 229A 625W TO264

DatasheetAPT100GN60LDQ4(G)

Package / CaseTO-264-3, TO-264AA

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionIGBT Trench Field Stop 600V 229A 625W Through Hole TO-264 [L]

To learn about the specification of APT100GN60LDQ4G, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add APT100GN60LDQ4G with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of APT100GN60LDQ4G.
We are offering APT100GN60LDQ4G for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

APT100GN60LDQ4G - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - IGBTs - Single
Datasheet	APT100GN60LDQ4(G)
Standard Package	1
Manufacturer	Microsemi Corporation
Series	-
Packaging	Tube
Part Status	Active
IGBT Type	Trench Field Stop
Voltage - Collector Emitter Breakdown (Max)	600V
Current - Collector (Ic) (Max)	229A
Current - Collector Pulsed (Icm)	300A
Vce(on) (Max) @ Vge, Ic	1.85V @ 15V, 100A
Power - Max	625W
Switching Energy	4.75mJ (on), 2.675mJ (off)
Input Type	Standard
Gate Charge	600nC
Td (on/off) @ 25°C	31ns/310ns
Test Condition	400V, 100A, 1Ohm, 15V
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-264-3, TO-264AA
Supplier Device Package	TO-264 [L]
