APTMC60TL11CT3AG

Part NumberAPTMC60TL11CT3AG

ManufacturerMicrosemi Corporation

DescriptionMOSFET 4N-CH 1200V 28A SP3

DatasheetAPTMC60TL11CT3AG

Package / CaseSP3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array 4 N-Channel (Three Level Inverter) 1200V (1.2kV) 28A (Tc) 125W Chassis Mount SP3

To learn about the specification of APTMC60TL11CT3AG, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add APTMC60TL11CT3AG with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of APTMC60TL11CT3AG.
We are offering APTMC60TL11CT3AG for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

APTMC60TL11CT3AG - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays

Datasheet

APTMC60TL11CT3AG

Standard Package

Manufacturer

Microsemi Corporation

Series

Packaging

Bulk

Part Status

Active

FET Type

4 N-Channel (Three Level Inverter)

FET Feature

Silicon Carbide (SiC)

Drain to Source Voltage (Vdss)

1200V (1.2kV)

Current - Continuous Drain (Id) @ 25°C

28A (Tc)

Rds On (Max) @ Id, Vgs

98mOhm @ 20A, 20V

Vgs(th) (Max) @ Id

2.2V @ 1mA

Gate Charge (Qg) (Max) @ Vgs

49nC @ 20V

Input Capacitance (Ciss) (Max) @ Vds

950pF @ 1000V

Power - Max

125W

Operating Temperature

-40°C ~ 150°C (TJ)

Mounting Type

Chassis Mount

Package / Case

SP3

Supplier Device Package

SP3
