ASPIAIG-H6530-100M-T


ASPIAIG-H6530-100M-T

Part NumberASPIAIG-H6530-100M-T

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

ASPIAIG-H6530-100M-T - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package1000
ManufacturerAbracon LLC
SeriesASPIAIG-H6530
PackagingTape & Reel (TR)
Part StatusActive
TypeWirewound
Material - CoreMetal
Inductance10µH
Tolerance±20%
Current Rating (Amps)4.2A
Current - Saturation4.45A
ShieldingShielded
DC Resistance (DCR)77.4mOhm
Q @ Freq-
Frequency - Self Resonant12MHz
RatingsAEC-Q200
Operating Temperature-40°C ~ 125°C
Inductance Frequency - Test100kHz
Mounting TypeSurface Mount
Package / CaseNonstandard
Supplier Device Package-
Size / Dimension0.280" L x 0.256" W (7.10mm x 6.50mm)
Height - Seated (Max)0.126" (3.20mm)
