B78108S1223K000
B78108S1223K000
Part Number B78108S1223K000 Description FIXED IND 22UH 560MA 740 MOHM TH Package / Case AxialUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 22µH Unshielded Wirewound Inductor 560mA 740mOhm Max Axial
To learn about the specification of B78108S1223K000, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add B78108S1223K000 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of B78108S1223K000.
We are offering B78108S1223K000 for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
B78108S1223K000 - Product Attributes
Categories
Inductors, Coils, Chokes / Fixed Inductors
Datasheet B78108S, B78148S Series Standard Package 1 Manufacturer EPCOS (TDK) Series BC Packaging Cut Tape (CT) Part Status Active Type Wirewound Material - Core Ferrite Inductance 22µH Tolerance ±10% Current Rating (Amps) 560mA Current - Saturation - Shielding Unshielded DC Resistance (DCR) 740mOhm Max Q @ Freq 55 @ 2.52MHz Frequency - Self Resonant 13MHz Ratings - Operating Temperature - Inductance Frequency - Test 2.52MHz Mounting Type Through Hole Package / Case Axial Supplier Device Package Axial Size / Dimension 0.157" Dia x 0.362" L (4.00mm x 9.20mm) Height - Seated (Max) -
