Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	B82144B2 Series
Standard Package	1
Manufacturer	EPCOS (TDK)
Series	LBC
Packaging	Cut Tape (CT)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	33µH
Tolerance	±5%
Current Rating (Amps)	1.9A
Current - Saturation	1.65A
Shielding	Unshielded
DC Resistance (DCR)	220mOhm Max
Q @ Freq	40 @ 252kHz
Frequency - Self Resonant	9MHz
Ratings	-
Operating Temperature	-55°C ~ 125°C
Inductance Frequency - Test	100kHz
Mounting Type	Through Hole
Package / Case	Radial, Vertical Cylinder
Supplier Device Package	-
Size / Dimension	0.256" Dia (6.50mm)
Height - Seated (Max)	0.551" (14.00mm)

B82144A2474J000	EPCOS (TDK), 470µH Unshielded Wirewound Inductor 280mA 2.5Ohm Max Axial, LBC	View
B82144B2182K000	EPCOS (TDK), 1.8µH Unshielded Wirewound Inductor 3.75A 50mOhm Max Radial, Vertical Cylinder, LBC	View
B82144A2102K000	EPCOS (TDK), 1µH Unshielded Wirewound Inductor 2.2A 80mOhm Max Axial, LBC	View
B82144A2226J000	EPCOS (TDK), 22mH Unshielded Wirewound Inductor 40mA 120Ohm Max Axial, LBC	View
B82144B2154J000	EPCOS (TDK), 150µH Unshielded Wirewound Inductor 1.05A 700mOhm Max Radial, Vertical Cylinder, LBC	View
B82144F2124J000	EPCOS (TDK), 120µH Unshielded Wirewound Inductor 1.1A 600mOhm Max Axial, LBC	View
B82144B2333J000	EPCOS (TDK), 33µH Unshielded Wirewound Inductor 1.9A 220mOhm Max Radial, Vertical Cylinder, LBC	View
B82144B2332K000	EPCOS (TDK), 3.3µH Unshielded Wirewound Inductor 3.5A 65mOhm Max Radial, Vertical Cylinder, LBC	View
B82144B2103K000	EPCOS (TDK), 10µH Unshielded Wirewound Inductor 2.45A 120mOhm Max Radial, Vertical Cylinder, LBC	View
B82144B2682K000	EPCOS (TDK), 6.8µH Unshielded Wirewound Inductor 2.75A 95mOhm Max Radial, Vertical Cylinder, LBC	View
B82144F2183K000	EPCOS (TDK), 18µH Unshielded Wirewound Inductor 2.2A 155mOhm Max Axial, LBC	View
B82144F2183K000	EPCOS (TDK), 18µH Unshielded Wirewound Inductor 2.2A 155mOhm Max Axial, LBC	View

B82144B2333J000

Part NumberB82144B2333J000
