Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	B82144B2 Series
Standard Package	1
Manufacturer	EPCOS (TDK)
Series	LBC
Packaging	Cut Tape (CT)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	82µH
Tolerance	±5%
Current Rating (Amps)	1.4A
Current - Saturation	1.1A
Shielding	Unshielded
DC Resistance (DCR)	400mOhm Max
Q @ Freq	40 @ 79.6kHz
Frequency - Self Resonant	6MHz
Ratings	-
Operating Temperature	-55°C ~ 125°C
Inductance Frequency - Test	100kHz
Mounting Type	Through Hole
Package / Case	Radial, Vertical Cylinder
Supplier Device Package	-
Size / Dimension	0.256" Dia (6.50mm)
Height - Seated (Max)	0.551" (14.00mm)

B82144F2474J000	EPCOS (TDK), 470µH Unshielded Wirewound Inductor 600mA 2.02Ohm Max Axial, LBC	View
B82144B2223K000	EPCOS (TDK), 22µH Unshielded Wirewound Inductor 2.1A 175mOhm Max Radial, Vertical Cylinder, LBC	View
B82144A2104J000	EPCOS (TDK), 100µH Unshielded Wirewound Inductor 600mA 700mOhm Max Axial, LBC	View
B82144B1225J000	EPCOS (TDK), 2.2mH Unshielded Wirewound Inductor 180mA 9.5Ohm Max Radial, Vertical Cylinder, LBC	View
B82144B2123K000	EPCOS (TDK), 12µH Unshielded Wirewound Inductor 2.4A 130mOhm Max Radial, Vertical Cylinder, LBC	View
B82144A2104J000	EPCOS (TDK), 100µH Unshielded Wirewound Inductor 600mA 700mOhm Max Axial, LBC	View
B82144A2223K000	EPCOS (TDK), 22µH Unshielded Wirewound Inductor 1.1A 350mOhm Max Axial, LBC	View
B82144F1105J000	EPCOS (TDK), 1mH Unshielded Wirewound Inductor 280mA 4.2Ohm Max Axial, LBC	View
B82144B2393J000	EPCOS (TDK), 39µH Unshielded Wirewound Inductor 1.75A 250mOhm Max Radial, Vertical Cylinder, LBC	View
B82144F2274J000	EPCOS (TDK), 270µH Unshielded Wirewound Inductor 800mA 1.2Ohm Max Axial, LBC	View
B82144B2272K000	EPCOS (TDK), 2.7µH Unshielded Wirewound Inductor 3.55A 60mOhm Max Radial, Vertical Cylinder, LBC	View
B82144B2334J000	EPCOS (TDK), 330µH Unshielded Wirewound Inductor 700mA 1.53Ohm Max Radial, Vertical Cylinder, LBC	View

B82144B2823J000

Part NumberB82144B2823J000
