Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	B82498F Series Datasheet
Standard Package	3000
Manufacturer	EPCOS (TDK)
Series	SIMID
Packaging	Tape & Reel (TR)
Part Status	Active
Type	Wirewound
Material - Core	Ceramic
Inductance	15nH
Tolerance	±5%
Current Rating (Amps)	650mA
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	130mOhm Max
Q @ Freq	50 @ 500MHz
Frequency - Self Resonant	3.3GHz
Ratings	-
Operating Temperature	-55°C ~ 125°C
Inductance Frequency - Test	250MHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	0805 (2012 Metric)
Size / Dimension	0.091" L x 0.067" W (2.30mm x 1.70mm)
Height - Seated (Max)	0.055" (1.40mm)

B82422A1103J100	EPCOS (TDK), 10µH Unshielded Wirewound Inductor 180mA 1.6Ohm Max 2-SMD, J-Lead, SIMID	View
B82442A1155K000	EPCOS (TDK), 1.5mH Unshielded Wirewound Inductor 70mA 16Ohm Max 2-SMD, J-Lead, SIMID	View
B82432T1154K000	EPCOS (TDK), 150µH Unshielded Wirewound Inductor 160mA 6Ohm Max 2-SMD, J-Lead, SIMID	View
B82442H1334K000	EPCOS (TDK), 330µH Unshielded Wirewound Inductor 200mA 3.92Ohm Max 2-SMD, J-Lead, SIMID	View
B82432T1824K000	EPCOS (TDK), 820µH Unshielded Wirewound Inductor 80mA 27Ohm Max 2-SMD, J-Lead, SIMID	View
B82442H1102K000	EPCOS (TDK), 1µH Unshielded Wirewound Inductor 2.5A 24mOhm Max 2-SMD, J-Lead, SIMID	View
B82496C3680J000	EPCOS (TDK), 68nH Unshielded Wirewound Inductor 230mA 1.3Ohm Max 0603 (1608 Metric), SIMID	View
B82422A3470K100	EPCOS (TDK), 47nH Unshielded Wirewound Inductor 510mA 190mOhm Max 2-SMD, J-Lead, SIMID	View
B82422A3151K100	EPCOS (TDK), 150nH Unshielded Wirewound Inductor 390mA 330mOhm Max 2-SMD, J-Lead, SIMID	View
B82422A3121J100	EPCOS (TDK), 120nH Unshielded Wirewound Inductor 400mA 320mOhm Max 2-SMD, J-Lead, SIMID	View
B82422T1104J000	EPCOS (TDK), 100µH Unshielded Wirewound Inductor 60mA 11Ohm Max 2-SMD, J-Lead, SIMID	View
B82442A1472K000	EPCOS (TDK), 4.7µH Unshielded Wirewound Inductor 950mA 88mOhm Max 2-SMD, J-Lead, SIMID	View

B82498F3150J000

Part NumberB82498F3150J000
