BD13516STU

BD13516STU

Part NumberBD13516STU

ManufacturerON Semiconductor

DescriptionTRANS NPN 45V 1.5A TO-126

DatasheetBD135 Overview

Package / CaseTO-225AA, TO-126-3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN 45V 1.5A 1.25W Through Hole TO-126-3

To learn about the specification of BD13516STU, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add BD13516STU with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of BD13516STU.
We are offering BD13516STU for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

BD13516STU - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Datasheet	BD135 Overview
Standard Package	1920
Manufacturer	ON Semiconductor
Series	-
Packaging	Tube
Part Status	Active
Transistor Type	NPN
Current - Collector (Ic) (Max)	1.5A
Voltage - Collector Emitter Breakdown (Max)	45V
Vce Saturation (Max) @ Ib, Ic	500mV @ 50mA, 500mA
Current - Collector Cutoff (Max)	100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	100 @ 150mA, 2V
Power - Max	1.25W
Frequency - Transition	-
Operating Temperature	150°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-225AA, TO-126-3
Supplier Device Package	TO-126-3
Base Part Number	BD135
