Categories	Filters / Ferrite Beads and Chips
Datasheet	BK Series, Chip Bead Inductors Catalog
Standard Package	10000
Manufacturer	Taiyo Yuden
Series	BK
Packaging	Tape & Reel (TR)
Part Status	Active
Filter Type	-
Number of Lines	1
Impedance @ Frequency	68 Ohms @ 100MHz
Current Rating (Max)	400mA
DC Resistance (DCR) (Max)	310mOhm
Ratings	-
Operating Temperature	-55°C ~ 125°C
Package / Case	0402 (1005 Metric)
Mounting Type	Surface Mount
Height (Max)	0.022" (0.55mm)
Size / Dimension	0.039" L x 0.020" W (1.00mm x 0.50mm)
