Categories	Filters / Ferrite Beads and Chips
Datasheet	BK20104M601-T View all Specification
Standard Package	4000
Manufacturer	Taiyo Yuden
Series	BK
Packaging	Tape & Reel (TR)
Part Status	Active
Filter Type	-
Number of Lines	4
Impedance @ Frequency	600 Ohms @ 100MHz
Current Rating (Max)	100mA
DC Resistance (DCR) (Max)	700mOhm
Ratings	-
Operating Temperature	-55°C ~ 125°C
Package / Case	0804 (2010 Metric), Array, 8 PC Pad
Mounting Type	Surface Mount
Height (Max)	0.020" (0.50mm)
Size / Dimension	0.079" L x 0.039" W (2.00mm x 1.00mm)
