BRL1608T100M


BRL1608T100M

Part NumberBRL1608T100M

Manufacturer

Description

Datasheet

Package / Case0603 (1608 Metric)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

BRL1608T100M - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package3000
ManufacturerTaiyo Yuden
SeriesBR, L Type
PackagingTape & Reel (TR)
Part StatusActive
TypeWirewound
Material - CoreFerrite
Inductance10µH
Tolerance±20%
Current Rating (Amps)220mA
Current - Saturation170mA
ShieldingUnshielded
DC Resistance (DCR)2.6Ohm Max
Q @ Freq-
Frequency - Self Resonant45MHz
Ratings-
Operating Temperature-40°C ~ 105°C
Inductance Frequency - Test1MHz
Mounting TypeSurface Mount
Package / Case0603 (1608 Metric)
Supplier Device Package0603 (1608 Metric)
Size / Dimension0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max)0.028" (0.70mm)
