Categories	Capacitors / Ceramic Capacitors
Datasheet	C Series, Low ESL Reverse Geometry
Standard Package	4000
Manufacturer	TDK Corporation
Series	C
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	2.2µF
Tolerance	±20%
Voltage - Rated	4V
Temperature Coefficient	X7S
Operating Temperature	-55°C ~ 125°C
Features	Low ESL (Reverse Geometry)
Ratings	-
Applications	Bypass, Decoupling
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	0306 (0816 Metric)
Size / Dimension	0.031" L x 0.063" W (0.80mm x 1.60mm)
Height - Seated (Max)	-
Thickness (Max)	0.024" (0.60mm)
Lead Spacing	-
Lead Style	-

C1608X5R0G156M080AA	TDK Corporation, 15µF ±20% 4V Ceramic Capacitor X5R 0603 (1608 Metric),	View
C1005NP01H151J050BA	TDK Corporation, 150pF ±5% 50V Ceramic Capacitor C0G, NP0 0402 (1005 Metric),	View
C0603C0G1H010C030BA	TDK Corporation, 1pF ±0.25pF 50V Ceramic Capacitor C0G, NP0 0201 (0603 Metric),	View
C2012X6S1C475M125AC	TDK Corporation, 4.7µF ±20% 16V Ceramic Capacitor X6S 0805 (2012 Metric),	View
C1608JB1H684M080AB	TDK Corporation, 0.68µF ±20% 50V Ceramic Capacitor JB 0603 (1608 Metric),	View
C1608C0G1H100D080AA	TDK Corporation, 10pF ±0.5pF 50V Ceramic Capacitor C0G, NP0 0603 (1608 Metric),	View
C1608X7S0G685M080AB	TDK Corporation, 6.8µF ±20% 4V Ceramic Capacitor X7S 0603 (1608 Metric),	View
C1005C0G1H681J050BA	TDK Corporation, 680pF ±5% 50V Ceramic Capacitor C0G, NP0 0402 (1005 Metric),	View
C1005X5R0G335K050BB	TDK Corporation, 3.3µF ±10% 4V Ceramic Capacitor X5R 0402 (1005 Metric),	View
C2012X7R1E225K125AB	TDK Corporation, 2.2µF ±10% 25V Ceramic Capacitor X7R 0805 (2012 Metric),	View
C2012X6S0G336M125AC	TDK Corporation, 33µF ±20% 4V Ceramic Capacitor X6S 0805 (2012 Metric),	View
C3216X7R1V106M160AC	TDK Corporation, 10µF ±20% 35V Ceramic Capacitor X7R 1206 (3216 Metric),	View

C0816X7S0G225M050AC

Part NumberC0816X7S0G225M050AC
