Categories	Capacitors / Ceramic Capacitors
Datasheet	High Voltage C0G Dielectric, Commercial
Standard Package	2500
Manufacturer	KEMET
Series	SMD Comm C0G HV
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	4700pF
Tolerance	±5%
Voltage - Rated	630V
Temperature Coefficient	C0G, NP0
Operating Temperature	-55°C ~ 125°C
Features	Low ESL, High Voltage
Ratings	-
Applications	General Purpose
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	1206 (3216 Metric)
Size / Dimension	0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max)	-
Thickness (Max)	0.087" (2.20mm)
Lead Spacing	-
Lead Style	-

C1206C330KCGACTU	KEMET, 33pF ±10% 500V Ceramic Capacitor C0G, NP0 1206 (3216 Metric), SMD Comm C0G HV	View
C0805C681JCGAC7800	KEMET, 680pF ±5% 500V Ceramic Capacitor C0G, NP0 0805 (2012 Metric), SMD Comm C0G HV	View
C1210C152JCGACTU	KEMET, 1500pF ±5% 500V Ceramic Capacitor C0G, NP0 1210 (3225 Metric), SMD Comm C0G HV	View
C0805C101JDGACTU	KEMET, 100pF ±5% 1000V (1kV) Ceramic Capacitor C0G, NP0 0805 (2012 Metric), SMD Comm C0G HV	View
C2225C152JGGACTU	KEMET, 1500pF ±5% 2000V (2kV) Ceramic Capacitor C0G, NP0 2225 (5763 Metric), SMD Comm C0G HV	View
C1812C101JDGAC7800	KEMET, 100pF ±5% 1000V (1kV) Ceramic Capacitor C0G, NP0 1812 (4532 Metric), SMD Comm C0G HV	View
C2225C392JGGACTU	KEMET, 3900pF ±5% 2000V (2kV) Ceramic Capacitor C0G, NP0 2225 (5763 Metric), SMD Comm C0G HV	View
C1812C561JFGAC7800	KEMET, 560pF ±5% 1500V (1.5kV) Ceramic Capacitor C0G, NP0 1812 (4532 Metric), SMD Comm C0G HV	View
C1206C470KGGACTU	KEMET, 47pF ±10% 2000V (2kV) Ceramic Capacitor C0G, NP0 1206 (3216 Metric), SMD Comm C0G HV	View
C2225C102KZGACTU	KEMET, 1000pF ±10% 2500V (2.5kV) Ceramic Capacitor C0G, NP0 2225 (5763 Metric), SMD Comm C0G HV	View
C2225C393JDGAC7800	KEMET, 0.039µF ±5% 1000V (1kV) Ceramic Capacitor C0G, NP0 2225 (5763 Metric), SMD Comm C0G HV	View
C0805C471JCGAC7800	KEMET, 470pF ±5% 500V Ceramic Capacitor C0G, NP0 0805 (2012 Metric), SMD Comm C0G HV	View

C1206C472JBGAC7800

Part NumberC1206C472JBGAC7800
