Categories	Capacitors / Ceramic Capacitors
Datasheet	High Voltage C0G Dielectric, Commercial
Standard Package	1
Manufacturer	KEMET
Series	SMD Comm C0G HV
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	10000pF
Tolerance	±5%
Voltage - Rated	1000V (1kV)
Temperature Coefficient	C0G, NP0
Operating Temperature	-55°C ~ 125°C
Features	Low ESL, High Voltage
Ratings	-
Applications	General Purpose
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	1210 (3225 Metric)
Size / Dimension	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)	-
Thickness (Max)	0.110" (2.80mm)
Lead Spacing	-
Lead Style	-
