Categories	Capacitors / Film Capacitors
Datasheet	CB Series Datasheet
Standard Package	400
Manufacturer	AVX Corporation
Series	CB
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	1µF
Tolerance	±5%
Voltage Rating - AC	160V
Voltage Rating - DC	250V
Dielectric Material	Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked
Operating Temperature	-55°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	6054 (153137 Metric)
Size / Dimension	0.602" L x 0.539" W (15.30mm x 13.70mm)
Height - Seated (Max)	0.236" (6.00mm)
Termination	Solder Pads
Lead Spacing	-
Applications	General Purpose
Ratings	-
Features	-

CBC2016T1R0M	Taiyo Yuden, 1µH Unshielded Wirewound Inductor 1.1A 130mOhm Max 0806 (2016 Metric), CB, C Type	View
CBC3225T102KRV	Taiyo Yuden, 1mH Unshielded Wirewound Inductor 75mA 16.9Ohm Max 1210 (3225 Metric), CB, C Type	View
CBC3225T680KR	Taiyo Yuden, 68µH Unshielded Wirewound Inductor 410mA 1.3Ohm Max 1210 (3225 Metric), CB, C Type	View
CB2016T100M	Taiyo Yuden, 10µH Unshielded Wirewound Inductor 520mA 650mOhm Max 0806 (2016 Metric), CB	View
CB2518T470K	Taiyo Yuden, 47µH Unshielded Wirewound Inductor 420mA 1.235Ohm Max 1007 (2518 Metric), CB	View
CBC2518T680K	Taiyo Yuden, 68µH Unshielded Wirewound Inductor 200mA 3.64Ohm Max 1007 (2518 Metric), CB, C Type	View
CB2016T220K	Taiyo Yuden, 22µH Unshielded Wirewound Inductor 370mA 1.3Ohm Max 0806 (2016 Metric), CB	View
CBC2518T100K	Taiyo Yuden, 10µH Unshielded Wirewound Inductor 680mA 468mOhm Max 1007 (2518 Metric), CB, C Type	View
CBC2518T151K	Taiyo Yuden, 150µH Unshielded Wirewound Inductor 130mA 7.93Ohm Max 1007 (2518 Metric), CB, C Type	View
CBC2016T330K	Taiyo Yuden, 33µH Unshielded Wirewound Inductor 220mA 3.64Ohm Max 0806 (2016 Metric), CB, C Type	View
CBC2012T220M	Taiyo Yuden, 22µH Unshielded Wirewound Inductor 190mA 4.81Ohm Max 0805 (2012 Metric), CB, C Type	View
CBC2518T681K	Taiyo Yuden, 680µH Unshielded Wirewound Inductor 60mA 36.4Ohm Max 1007 (2518 Metric), CB, C Type	View

CB182G0105JBC

Part NumberCB182G0105JBC
