Categories	Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Datasheet	CBR1-D020,40,60,80,100S
Standard Package	1
Manufacturer	Central Semiconductor Corp
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Single Phase
Technology	Standard
Voltage - Peak Reverse (Max)	600V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	1.1V @ 1A
Current - Reverse Leakage @ Vr	10µA @ 600V
Operating Temperature	-65°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	4-SMD, Gull Wing
Supplier Device Package	4-SMDIP
Base Part Number	CBR1-D060

MDB6S	ON Semiconductor, Bridge Rectifier Single Phase Standard 600V Surface Mount 4-MicroDIP/SMD,	View
NSR1030QMUTWG	ON Semiconductor, Bridge Rectifier Single Phase Schottky 30V Surface Mount 4-UDFN (3x3),	View
RABF1510-13	Diodes Incorporated, Bridge Rectifier Single Phase Standard 1kV Surface Mount 4-SOPA,	View
LMB8S-TP	Micro Commercial Co, Bridge Rectifier Single Phase Standard 800V Surface Mount LMBS-1,	View
DF15005S-T	Diodes Incorporated, Bridge Rectifier Single Phase Standard 50V Surface Mount DF-S,	View
ABS210-13	Diodes Incorporated, Bridge Rectifier Single Phase Standard 1kV Surface Mount 4-SOPA,	View
YBS3004G	Taiwan Semiconductor Corporation, Bridge Rectifier Single Phase Standard 400V Surface Mount YBS,	View
MB6S-TP	Micro Commercial Co, Bridge Rectifier Single Phase Standard 600V Surface Mount MBS-1,	View
CBR1-D040S TR13	Central Semiconductor Corp, Bridge Rectifier Single Phase Standard 400V Surface Mount 4-SMDIP,	View
DBLS157G RDG	Taiwan Semiconductor Corporation, Bridge Rectifier Single Phase Standard 1kV Surface Mount DBLS,	View
RH04-T	Diodes Incorporated, Bridge Rectifier Single Phase Standard 400V Surface Mount 4-MiniDIP,	View
SDB107-TP	Micro Commercial Co, Bridge Rectifier Single Phase Standard 1kV Surface Mount SDB-1,	View

CBR1-D060S TR13
