Categories	Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Datasheet	CBRLDSH2-40
Standard Package	4000
Manufacturer	Central Semiconductor Corp
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Diode Type	Single Phase
Technology	Schottky
Voltage - Peak Reverse (Max)	40V
Current - Average Rectified (Io)	2A
Voltage - Forward (Vf) (Max) @ If	500mV @ 2A
Current - Reverse Leakage @ Vr	100µA @ 40V
Operating Temperature	-55°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Package / Case	4-SMD, Gull Wing
Supplier Device Package	4-LPDIP
