Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Standard Package	1
Manufacturer	Toshiba Semiconductor and Storage
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	30V
Current - Average Rectified (Io)	500mA
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	50µA @ 30V
Capacitance @ Vr, F	118pF @ 0V, 1MHz
Mounting Type	Surface Mount
Package / Case	SOD-882
Supplier Device Package	CST2B
Operating Temperature - Junction	125°C (Max)

MMBD330T1G	ON Semiconductor, RF Diode Schottky - Single 30V 200mA 120mW SC-70-3 (SOT323),	View
SMS7630-005LF	Skyworks Solutions Inc., RF Diode Schottky - 1 Pair Series Connection 2V 50mA 75mW SOT-23-3,	View
CCS15F40,L3F	Toshiba Semiconductor and Storage, Diode Schottky 40V 1.5A Surface Mount CST2C,	View
MBD770DWT1G	ON Semiconductor, RF Diode Schottky - 2 Independent 70V 100mA 380mW SC-88/SC70-6/SOT-363,	View
CUS05S40,H3F	Toshiba Semiconductor and Storage, Diode Schottky 40V 500mA Surface Mount USC,	View
CTS520,L3F	Toshiba Semiconductor and Storage, Diode Schottky 30V 200mA Surface Mount CST2,	View
CRS11(TE85L,Q,M)	Toshiba Semiconductor and Storage, Diode Schottky 30V 1A Surface Mount S-FLAT (1.6x3.5),	View
CUHS20S40,H3F	Toshiba Semiconductor and Storage, Diode Schottky 40V 2A Surface Mount US2H,	View
CMS11(TE12L,Q,M)	Toshiba Semiconductor and Storage, Diode Schottky 40V 2A Surface Mount M-FLAT (2.4x3.8),	View
MMBD770T1G	ON Semiconductor, RF Diode Schottky - Single 70V 200mA 120mW SC-70-3 (SOT323),	View
CUHS10F60,H3F	Toshiba Semiconductor and Storage, Diode Schottky 60V 1A Surface Mount US2H,	View
1SS413CT,L3F	Toshiba Semiconductor and Storage, Diode Schottky 20V 50mA Surface Mount SOD-882,	View

CBS05F30,L3F

Part NumberCBS05F30,L3F
