Categories	Capacitors / Ceramic Capacitors
Datasheet	CGA Series, Automotive General Catalog
Standard Package	1
Manufacturer	TDK Corporation
Series	CGA
Packaging	Cut Tape (CT)
Part Status	Not For New Designs
Capacitance	1.5µF
Tolerance	±10%
Voltage - Rated	25V
Temperature Coefficient	X5R
Operating Temperature	-55°C ~ 85°C
Features	-
Ratings	AEC-Q200
Applications	Automotive
Failure Rate	-
Mounting Type	Surface Mount, MLCC
Package / Case	1206 (3216 Metric)
Size / Dimension	0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max)	-
Thickness (Max)	0.075" (1.90mm)
Lead Spacing	-
Lead Style	-
