Categories	Resistors / Chip Resistor - Surface Mount
Datasheet	CH Series Datasheet
Standard Package	1
Manufacturer	Vishay Sfernice
Series	CH
Packaging	Cut Tape (CT)
Part Status	Active
Resistance	10 Ohms
Tolerance	±5%
Power (Watts)	0.03W, 1/32W
Composition	Thin Film
Features	-
Temperature Coefficient	±100ppm/°C
Operating Temperature	-55°C ~ 155°C
Package / Case	Nonstandard
Supplier Device Package	2016
Size / Dimension	0.019" L x 0.015" W (0.48mm x 0.39mm)
Height - Seated (Max)	0.022" (0.55mm)
Number of Terminations	2
Failure Rate	-
