Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	CMS10
Standard Package	3000
Manufacturer	Toshiba Semiconductor and Storage
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	40V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	550mV @ 1A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	500µA @ 40V
Capacitance @ Vr, F	50pF @ 10V, 1MHz
Mounting Type	Surface Mount
Package / Case	SOD-128
Supplier Device Package	M-FLAT (2.4x3.8)
Operating Temperature - Junction	-40°C ~ 150°C
Base Part Number	CMS10

CMS04(TE12L,Q,M)	Toshiba Semiconductor and Storage, Diode Schottky 30V 5A Surface Mount M-FLAT (2.4x3.8),	View
MMDL301T1G	ON Semiconductor, RF Diode Schottky - Single 30V 200mW SOD-323,	View
CMS05(TE12L,Q,M)	Toshiba Semiconductor and Storage, Diode Schottky 30V 5A Surface Mount M-FLAT (2.4x3.8),	View
CRS06(TE85L,Q,M)	Toshiba Semiconductor and Storage, Diode Schottky 20V 1A Surface Mount S-FLAT (1.6x3.5),	View
CES520,L3F	Toshiba Semiconductor and Storage, Diode Schottky 30V 200mA Surface Mount ESC,	View
CRS04(TE85L,Q,M)	Toshiba Semiconductor and Storage, Diode Schottky 40V 1A Surface Mount S-FLAT (1.6x3.5),	View
1SS404,H3F	Toshiba Semiconductor and Storage, Diode Schottky 20V 300mA Surface Mount USC,	View
MMBD354LT1G	ON Semiconductor, RF Diode Schottky - 1 Pair Common Cathode 7V 225mW SOT-23-3 (TO-236),	View
MMBD353LT1G	ON Semiconductor, RF Diode Schottky - 1 Pair Series Connection 7V 225mW SOT-23-3 (TO-236),	View
SMS7621-040LF	Skyworks Solutions Inc., RF Diode Schottky - Single 2V 150mA 750mW 0402,	View
CRS03(TE85L,Q,M)	Toshiba Semiconductor and Storage, Diode Schottky 30V 1A Surface Mount S-FLAT (1.6x3.5),	View
1SS413CT,L3F	Toshiba Semiconductor and Storage, Diode Schottky 20V 50mA Surface Mount SOD-882,	View

CMS10(TE12L,Q,M)
