CPFC74NP-CB08M6

Part NumberCPFC74NP-CB08M6

ManufacturerSumida America Components Inc.

DescriptionCMC 2LN 800 OHM SMD

DatasheetCPFC74 Series Datasheet

Package / CaseVertical, 4 Gull Wing

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description2 Line Common Mode Choke Surface Mount 800 Ohms @ 10MHz DCR 500mOhm

To learn about the specification of CPFC74NP-CB08M6, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add CPFC74NP-CB08M6 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of CPFC74NP-CB08M6.
We are offering CPFC74NP-CB08M6 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

CPFC74NP-CB08M6 - Product Attributes

Categories

Filters / Common Mode Chokes

Datasheet

CPFC74 Series Datasheet

Standard Package

1000

Manufacturer

Sumida America Components Inc.

Series

CPFC

Packaging

Tape & Reel (TR)

Part Status

Active

Filter Type

Power Line

Number of Lines

Impedance @ Frequency

800 Ohms @ 10MHz

Current Rating (Max)

DC Resistance (DCR) (Max)

500mOhm

Voltage Rating - DC

Voltage Rating - AC

Operating Temperature

Ratings

Approvals

Features

Mounting Type

Surface Mount

Size / Dimension

0.374" L x 0.224" W (9.50mm x 5.70mm)

Height (Max)

0.200" (5.08mm)

Package / Case

Vertical, 4 Gull Wing
