DMN1003UCA6-7


DMN1003UCA6-7

Part NumberDMN1003UCA6-7

Manufacturer

Description

Datasheet

Package / Case6-SMD, No Lead

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

DMN1003UCA6-7 - Product Attributes

Categories Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Datasheet
Standard Package3000
ManufacturerDiodes Incorporated
Series-
PackagingTape & Reel (TR)
Part StatusActive
FET Type2 N-Channel (Dual)
FET FeatureStandard
Drain to Source Voltage (Vdss)-
Current - Continuous Drain (Id) @ 25°C-
Rds On (Max) @ Id, Vgs-
Vgs(th) (Max) @ Id1.3V @ 1mA
Gate Charge (Qg) (Max) @ Vgs56.5nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds3315pF @ 6V
Power - Max2.67W
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Package / Case6-SMD, No Lead
Supplier Device PackageX3-DSN3518-6
