DSC8101AL2T

Part NumberDSC8101AL2T

ManufacturerMicrochip Technology

DescriptionMEMS OSC PROG BLANK 10MHZ-170MHZ

DatasheetDSC8101,21 Datasheet

Package / Case6-SMD, No Lead Exposed Pad

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionXO (Standard) CMOS 10MHz ~ 170MHz Programmable Oscillator 2.25V ~ 3.6V Standby 6-SMD, No Lead Exposed Pad

To learn about the specification of DSC8101AL2T, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add DSC8101AL2T with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of DSC8101AL2T.
We are offering DSC8101AL2T for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

DSC8101AL2T - Product Attributes

Categories

Crystals, Oscillators, Resonators / Programmable Oscillators

Datasheet

DSC8101,21 Datasheet

Standard Package

1000

Manufacturer

Microchip Technology

Series

DSC8101

Packaging

Tape & Reel (TR)

Part Status

Active

Base Resonator

MEMS

Type

XO (Standard)

Programmable Type

Blank (User Must Program)

Available Frequency Range

10MHz ~ 170MHz

Function

Standby

Output

CMOS

Voltage - Supply

2.25V ~ 3.6V

Frequency Stability

±25ppm

Frequency Stability (Total)

Operating Temperature

-40°C ~ 105°C

Spread Spectrum Bandwidth

Current - Supply (Max)

35mA

Ratings

AEC-Q100

Mounting Type

Surface Mount

Package / Case

6-SMD, No Lead Exposed Pad

Size / Dimension

0.276" L x 0.197" W (7.00mm x 5.00mm)

Height - Seated (Max)

0.035" (0.90mm)

Current - Supply (Disable) (Max)

95µA
