EEA-GA1E220

Part NumberEEA-GA1E220

ManufacturerPanasonic Electronic Components

DescriptionCAP ALUM 22UF 20% 25V RADIAL

DatasheetGA Series Datasheet

Package / CaseRadial, Can

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description22µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C

To learn about the specification of EEA-GA1E220, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add EEA-GA1E220 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of EEA-GA1E220.
We are offering EEA-GA1E220 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

EEA-GA1E220 - Product Attributes

Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	GA Series Datasheet
Standard Package	200
Manufacturer	Panasonic Electronic Components
Series	GA
Packaging	Bulk
Part Status	Active
Capacitance	22µF
Tolerance	±20%
Voltage - Rated	25V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	50mA @ 120Hz
Ripple Current @ High Frequency	77.5mA @ 100kHz
Lead Spacing	0.079" (2.00mm)
Size / Dimension	0.197" Dia (5.00mm)
Height - Seated (Max)	0.276" (7.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can
