EEE-FT1E102UP

Part NumberEEE-FT1E102UP

ManufacturerPanasonic Electronic Components

DescriptionCAP ALUM 1000UF 20% 25V SMD

DatasheetFT Series, Type V, Datasheet

Package / CaseRadial, Can - SMD

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description1000µF 25V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 105°C

To learn about the specification of EEE-FT1E102UP, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add EEE-FT1E102UP with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of EEE-FT1E102UP.
We are offering EEE-FT1E102UP for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

EEE-FT1E102UP - Product Attributes

Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	FT Series, Type V, Datasheet
Standard Package	500
Manufacturer	Panasonic Electronic Components
Series	FT
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	1000µF
Tolerance	±20%
Voltage - Rated	25V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	Polar
Ratings	AEC-Q200
Applications	Automotive, High Temperature Reflow
Ripple Current @ Low Frequency	833mA @ 120Hz
Ripple Current @ High Frequency	1.19A @ 100kHz
Lead Spacing	-
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.413" (10.50mm)
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD
