EEE-HBH220UAP

Part NumberEEE-HBH220UAP

ManufacturerPanasonic Electronic Components

DescriptionCAP ALUM 22UF 20% 50V SMD

DatasheetEEE-HB Series, Type V (Suffix A)

Package / CaseRadial, Can - SMD

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description22µF 50V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 105°C

To learn about the specification of EEE-HBH220UAP, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add EEE-HBH220UAP with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of EEE-HBH220UAP.
We are offering EEE-HBH220UAP for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

EEE-HBH220UAP - Product Attributes

Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	EEE-HB Series, Type V (Suffix A)
Standard Package	1
Manufacturer	Panasonic Electronic Components
Series	HB
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	22µF
Tolerance	±20%
Voltage - Rated	50V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	AEC-Q200
Applications	Automotive
Ripple Current @ Low Frequency	35mA @ 120Hz
Ripple Current @ High Frequency	59.5mA @ 10kHz
Lead Spacing	-
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.228" (5.80mm)
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD
