EEE-TP1J102V

Part NumberEEE-TP1J102V

ManufacturerPanasonic Electronic Components

DescriptionFIXED ALUMINUM ELECTROLYTIC CAPA

DatasheetEEE-TP Series, Type V, Med Sz

Package / CaseRadial, Can - SMD

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description1000µF 63V Aluminum Electrolytic Capacitors Radial, Can - SMD 68mOhm @ 100kHz 4000 Hrs @ 125°C

To learn about the specification of EEE-TP1J102V, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add EEE-TP1J102V with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of EEE-TP1J102V.
We are offering EEE-TP1J102V for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

EEE-TP1J102V - Product Attributes

Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	EEE-TP Series, Type V, Med Sz
Standard Package	1
Manufacturer	Panasonic Electronic Components
Series	TP
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	1000µF
Tolerance	±20%
Voltage - Rated	63V
ESR (Equivalent Series Resistance)	68mOhm @ 100kHz
Lifetime @ Temp.	4000 Hrs @ 125°C
Operating Temperature	-55°C ~ 125°C
Polarization	Polar
Ratings	AEC-Q200
Applications	Automotive, High Temperature Reflow
Ripple Current @ Low Frequency	1.95A @ 120Hz
Ripple Current @ High Frequency	2.6A @ 100kHz
Lead Spacing	-
Size / Dimension	0.709" Dia (18.00mm)
Height - Seated (Max)	0.866" (22.00mm)
Surface Mount Land Size	0.748" L x 0.748" W (19.00mm x 19.00mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD
