EKMG101ELL220MHB5D

Part NumberEKMG101ELL220MHB5D

To learn about the specification of EKMG101ELL220MHB5D, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add EKMG101ELL220MHB5D with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of EKMG101ELL220MHB5D.
We are offering EKMG101ELL220MHB5D for competitive price in the global market, please send us a quota request for pricing. Thank you!

Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	KMG Series Datasheet
Standard Package	1000
Manufacturer	United Chemi-Con
Series	KMG
Packaging	Bulk
Part Status	Active
Capacitance	22µF
Tolerance	±20%
Voltage - Rated	100V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	93mA @ 120Hz
Ripple Current @ High Frequency	167.4mA @ 100kHz
Lead Spacing	0.138" (3.50mm)
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.512" (13.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can
