Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	EPC2024 Datasheet
Standard Package	500
Manufacturer	EPC
Series	eGaN®
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	GaNFET (Gallium Nitride)
Drain to Source Voltage (Vdss)	40V
Current - Continuous Drain (Id) @ 25°C	60A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	5V
Rds On (Max) @ Id, Vgs	1.5mOhm @ 37A, 5V
Vgs(th) (Max) @ Id	2.5V @ 19mA
Vgs (Max)	+6V, -4V
Input Capacitance (Ciss) (Max) @ Vds	2100pF @ 20V
FET Feature	-
Power Dissipation (Max)	-
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	Die
Package / Case	Die

EPC2031ENGRT	EPC, N-Channel 60V 31A (Ta) Surface Mount Die, eGaN®	View
TPH3208LSG	Transphorm, N-Channel 650V 20A (Tc) 96W (Tc) Surface Mount 3-PQFN (8x8),	View
EPC2007C	EPC, N-Channel 100V 6A (Ta) Surface Mount Die Outline (5-Solder Bar), eGaN®	View
EPC2015C	EPC, N-Channel 40V 53A (Ta) Surface Mount Die, eGaN®	View
EPC2024	EPC, N-Channel 40V 60A (Ta) Surface Mount Die, eGaN®	View
EPC2019	EPC, N-Channel 200V 8.5A (Ta) Surface Mount Die, eGaN®	View
EPC2036	EPC, N-Channel 100V 1.7A (Ta) Surface Mount Die, eGaN®	View
EPC2203	EPC, N-Channel 80V 1.7A Surface Mount Die, Automotive, AEC-Q101, eGaN®	View
EPC2045	EPC, N-Channel 100V 16A (Ta) Surface Mount Die, eGaN®	View
EPC2014C	EPC, N-Channel 40V 10A (Ta) Surface Mount Die Outline (5-Solder Bar), eGaN®	View
EPC2031ENGRT	EPC, N-Channel 60V 31A (Ta) Surface Mount Die, eGaN®	View
EPC2020	EPC, N-Channel 60V 90A (Ta) Surface Mount Die, eGaN®	View

EPC2024
