EPC2105

Part NumberEPC2105

ManufacturerEPC

DescriptionGAN TRANS ASYMMETRICAL HALF BRID

DatasheetEPC2105 Preliminary

Package / CaseDie

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array 2 N-Channel (Half Bridge) 80V 9.5A, 38A Surface Mount Die

To learn about the specification of EPC2105, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add EPC2105 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of EPC2105.
We are offering EPC2105 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

EPC2105 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Datasheet	EPC2105 Preliminary
Standard Package	500
Manufacturer	EPC
Series	eGaN®
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	2 N-Channel (Half Bridge)
FET Feature	GaNFET (Gallium Nitride)
Drain to Source Voltage (Vdss)	80V
Current - Continuous Drain (Id) @ 25°C	9.5A, 38A
Rds On (Max) @ Id, Vgs	14.5mOhm @ 20A, 5V, 3.4mOhm @ 20A, 5V
Vgs(th) (Max) @ Id	2.5V @ 2.5mA, 2.5V @ 10mA
Gate Charge (Qg) (Max) @ Vgs	2.5nC @ 5V, 10nC @ 5V
Input Capacitance (Ciss) (Max) @ Vds	300pF @ 40V, 1100pF @ 40V
Power - Max	-
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	Die
Supplier Device Package	Die
