ER1537-30KR

ER1537-30KR

Part NumberER1537-30KR

ManufacturerAPI Delevan Inc.

DescriptionFIXED IND 5.6UH 495MA 320 MOHM

DatasheetER Series (MIL-PRF-39010)

Package / CaseAxial

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description5.6µH Unshielded Inductor 495mA 320mOhm Max Axial

To learn about the specification of ER1537-30KR, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add ER1537-30KR with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of ER1537-30KR.
We are offering ER1537-30KR for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

ER1537-30KR - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	ER Series (MIL-PRF-39010)
Standard Package	250
Manufacturer	API Delevan Inc.
Series	Military, MIL-PRF-39010/07, ER1537
Packaging	Tape & Reel (TR)
Part Status	Active
Type	-
Material - Core	Iron
Inductance	5.6µH
Tolerance	±10%
Current Rating (Amps)	495mA
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	320mOhm Max
Q @ Freq	45 @ 7.9MHz
Frequency - Self Resonant	60MHz
Ratings	-
Operating Temperature	-55°C ~ 105°C
Inductance Frequency - Test	7.9MHz
Mounting Type	Through Hole
Package / Case	Axial
Supplier Device Package	Axial
Size / Dimension	0.156" Dia x 0.375" L (3.96mm x 9.53mm)
Height - Seated (Max)	-
