ER1840-01JS

ER1840-01JS

Part NumberER1840-01JS

ManufacturerAPI Delevan Inc.

DescriptionFIXED IND 180NH 2.7A 35 MOHM TH

DatasheetER Series (MIL-PRF-39010)

Package / CaseAxial

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description180nH Unshielded Inductor 2.7A 35mOhm Max Axial

To learn about the specification of ER1840-01JS, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add ER1840-01JS with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of ER1840-01JS.
We are offering ER1840-01JS for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

ER1840-01JS - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	ER Series (MIL-PRF-39010)
Standard Package	250
Manufacturer	API Delevan Inc.
Series	Military, MIL-PRF-39010/04, ER1840
Packaging	Tape & Reel (TR)
Part Status	Active
Type	-
Material - Core	Phenolic
Inductance	180nH
Tolerance	±5%
Current Rating (Amps)	2.7A
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	35mOhm Max
Q @ Freq	50 @ 25MHz
Frequency - Self Resonant	415MHz
Ratings	-
Operating Temperature	-55°C ~ 125°C
Inductance Frequency - Test	25MHz
Mounting Type	Through Hole
Package / Case	Axial
Supplier Device Package	Axial
Size / Dimension	0.187" Dia x 0.437" L (4.75mm x 11.10mm)
Height - Seated (Max)	-
