FDMC8010DC

FDMC8010DC

Part NumberFDMC8010DC

ManufacturerON Semiconductor

DescriptionMOSFET 2 N-CH 30V 157A 8-PQFN

DatasheetFDMC8010DC

Package / Case8-PowerWDFN

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 30V 37A (Ta) 3W (Ta) Surface Mount 8-PQFN (3.3x3.3)

To learn about the specification of FDMC8010DC, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add FDMC8010DC with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of FDMC8010DC.
We are offering FDMC8010DC for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

FDMC8010DC - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	FDMC8010DC
Standard Package	3000
Manufacturer	ON Semiconductor
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	30V
Current - Continuous Drain (Id) @ 25°C	37A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	1.28mOhm @ 37A, 10V
Vgs(th) (Max) @ Id	3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	94nC @ 15V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	7080pF @ 15V
FET Feature	Standard
Power Dissipation (Max)	3W (Ta)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	8-PQFN (3.3x3.3)
Package / Case	8-PowerWDFN
