Categories	Capacitors / Electric Double Layer Capacitors (EDLC), Supercapacitors
Datasheet	FG Series Datasheet
Standard Package	160
Manufacturer	KEMET
Series	FG
Packaging	Bulk
Part Status	Active
Capacitance	1.5F
Tolerance	-20%, +80%
Voltage - Rated	3.5V
ESR (Equivalent Series Resistance)	65Ohm @ 1kHz
Lifetime @ Temp.	-
Termination	PC Pins
Mounting Type	Through Hole
Package / Case	Radial, Can
Lead Spacing	0.200" (5.08mm)
Size / Dimension	0.650" Dia (16.50mm)
Height - Seated (Max)	0.551" (14.00mm)
Operating Temperature	-25°C ~ 70°C
