Categories	Discrete Semiconductor Products / Transistors - IGBTs - Single
Datasheet	FGA50N100BNTD
Standard Package	450
Manufacturer	ON Semiconductor
Series	-
Packaging	Tube
Part Status	Active
IGBT Type	NPT and Trench
Voltage - Collector Emitter Breakdown (Max)	1000V
Current - Collector (Ic) (Max)	50A
Current - Collector Pulsed (Icm)	100A
Vce(on) (Max) @ Vge, Ic	2.9V @ 15V, 60A
Power - Max	156W
Switching Energy	-
Input Type	Standard
Gate Charge	275nC
Td (on/off) @ 25°C	-
Test Condition	-
Reverse Recovery Time (trr)	1.5µs
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-3P-3, SC-65-3
Supplier Device Package	TO-3P
