Categories	Discrete Semiconductor Products / Transistors - IGBTs - Single
Datasheet	FGH75T65SQDTL4
Standard Package	450
Manufacturer	ON Semiconductor
Series	-
Packaging	Tube
Part Status	Active
IGBT Type	Trench Field Stop
Voltage - Collector Emitter Breakdown (Max)	650V
Current - Collector (Ic) (Max)	150A
Current - Collector Pulsed (Icm)	300A
Vce(on) (Max) @ Vge, Ic	2.1V @ 15V, 75A
Switching Energy	307µJ (on), 266µJ (off)
Input Type	Standard
Gate Charge	128nC
Td (on/off) @ 25°C	44ns/276ns
Test Condition	400V, 18.8A, 15Ohm, 15V
Reverse Recovery Time (trr)	76ns
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-247-4
Supplier Device Package	TO-247
