Categories	Capacitors / Film Capacitors
Datasheet	WIMA FKP 1
Standard Package	2400
Manufacturer	WIMA
Series	-
Packaging	Bulk
Part Status	Active
Capacitance	470pF
Tolerance	±20%
Voltage Rating - AC	650V
Voltage Rating - DC	1600V (1.6kV)
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 100°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.709" L x 0.197" W (18.00mm x 5.00mm)
Height - Seated (Max)	0.433" (11.00mm)
Termination	PC Pins
Lead Spacing	0.591" (15.00mm)
Applications	High Frequency, Switching; High Pulse, DV/DT
Ratings	-
Features	-

FKP1U002204B00KSSD	WIMA, 220pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
FKP1G031005H00JSSD	WIMA, 0.1µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
FKP1G032206D00MSSD	WIMA, 0.22µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
FKP1U014705F00KSSD	WIMA, 4700pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
FKP1O113304B00KSSD	WIMA, 3300pF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial,	View
FKP1O111004B00JSSD	WIMA, 1000pF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial,	View
FKP1X004705A00JSSD	WIMA, 470pF Film Capacitor 700V 4000V (4kV) Polypropylene (PP), Metallized Radial,	View
FKP1T006804B00JSD0	WIMA, 680pF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
FKP1X004705A00KSSD	WIMA, 470pF Film Capacitor 700V 4000V (4kV) Polypropylene (PP), Metallized Radial,	View
FKP1U023307C00MSSD	WIMA, 0.033µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
FKP1G032206D00KSSD	WIMA, 0.22µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
FKP1R016804F00KSSD	WIMA, 6800pF Film Capacitor 600V 1250V (1.25kV) Polypropylene (PP), Metallized Radial,	View

FKP1T004704B00MSSD

Part NumberFKP1T004704B00MSSD
