Categories	Capacitors / Film Capacitors
Datasheet	WIMA FKP 1
Standard Package	594
Manufacturer	WIMA
Series	-
Packaging	Bulk
Part Status	Active
Capacitance	3300pF
Tolerance	±10%
Voltage Rating - AC	700V
Voltage Rating - DC	6000V (6kV)
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 100°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.043" L x 0.413" W (26.50mm x 10.50mm)
Height - Seated (Max)	0.807" (20.50mm)
Termination	PC Pins
Lead Spacing	0.886" (22.50mm)
Applications	High Frequency, Switching; High Pulse, DV/DT
Ratings	-
Features	-

FKP1U001504B00KSSD	WIMA, 150pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial,	View
FKP1X011005A00JSSD	WIMA, 1000pF Film Capacitor 700V 4000V (4kV) Polypropylene (PP), Metallized Radial,	View
FKP1T021005H00MSC9	WIMA, 10000pF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
FKP1T004704B00MSSD	WIMA, 470pF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
FKP1T011504D00JSSD	WIMA, 1500pF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial,	View
FKP1G022205A00MSSD	WIMA, 0.022µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
FKP1Y021006F00JSSD	WIMA, 10000pF Film Capacitor 700V 6000V (6kV) Polypropylene (PP), Metallized Radial,	View
FKP1G031005H00MSSD	WIMA, 0.1µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
FKP1G024705D00KSSD	WIMA, 0.047µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial,	View
FKP1O124706B00JSSD	WIMA, 0.047µF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial,	View
FKP1Y021006F00MSSD	WIMA, 10000pF Film Capacitor 700V 6000V (6kV) Polypropylene (PP), Metallized Radial,	View
FKP1X004705A00KSSD	WIMA, 470pF Film Capacitor 700V 4000V (4kV) Polypropylene (PP), Metallized Radial,	View

FKP1Y013305H00KSC9

Part NumberFKP1Y013305H00KSC9
