Categories	Crystals, Oscillators, Resonators / Crystals
Datasheet	FL0800011Q Spec Sheet
Standard Package	3000
Manufacturer	Diodes Incorporated
Series	SaRonix-eCera™ FL
Packaging	Tape & Reel (TR)
Part Status	Active
Type	MHz Crystal
Frequency	8MHz
Frequency Stability	±60ppm
Frequency Tolerance	±30ppm
Load Capacitance	12pF
ESR (Equivalent Series Resistance)	600 Ohms
Operating Mode	Fundamental
Operating Temperature	-40°C ~ 125°C
Ratings	AEC-Q200
Mounting Type	Surface Mount
Package / Case	4-SMD, No Lead
Size / Dimension	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)	0.031" (0.78mm)
