FP2-S100-R

FP2-S100-R

Part NumberFP2-S100-R

ManufacturerEaton - Electronics Division

DescriptionFIXED IND 100NH 39A 0.24 MOHM

DatasheetFP2 Series FLAT-PAC

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description100nH Unshielded Wirewound Inductor 39A 0.24mOhm Nonstandard

To learn about the specification of FP2-S100-R, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add FP2-S100-R with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of FP2-S100-R.
We are offering FP2-S100-R for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

FP2-S100-R - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	FP2 Series FLAT-PAC
Standard Package	1700
Manufacturer	Eaton - Electronics Division
Series	FLAT-PAC
Packaging	Tape & Reel (TR)
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	100nH
Tolerance	±15%
Current Rating (Amps)	39A
Current - Saturation	22A
Shielding	Unshielded
DC Resistance (DCR)	0.24mOhm
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-40°C ~ 125°C
Inductance Frequency - Test	1MHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.283" L x 0.264" W (7.20mm x 6.70mm)
Height - Seated (Max)	0.118" (3.00mm)
